Our Polyester Pull Tape (also known as Mule Tape) is an industrial-grade, high-performance solution engineered for the most demanding cable-pulling environments. We Manufactured it from 100% high-tenacity woven polyester, this flat-profile tape is designed to replace traditional ropes, offering superior strength-to-weight ratios and enhanced safety for utility, telecommunications, and electrical professionals.
Its ribbon-like design ensures even distribution of pulling forces, which significantly reduces the risk of burn-through and damage to both the cable jacket and the conduit interior during long or complex runs.
| Tape Width | Tensile Strength (kgf) | Tensile Strength (Lbf) | Common Lengths | Application Level |
|---|---|---|---|---|
| 1/2" (13mm) | 567 kgs | 1250 lbs | 500' / 1000' / 3000' | Light-duty residential/commercial |
| 5/8" (16mm) | 816 - 998 kgs | 1800 - 2200 lbs | 500' / 1,000' / 3,000' / 5,000' | Standard industrial conduit pulls |
| 3/4" (19mm) | 998 - 1134 kgs | 2200 - 2500 lbs | 500' / 1,000' / 3,000' / 5,000' | Heavy-duty electrical & telecom |
| 1" (25mm) | 1134 - 2722 kgs | 2500 - 6000 lbs | Custom / Extended reels | Ultra-heavy utility pulls |
* Larger sizes available on specialized orders.
At BMG ROPES PVT LTD, we recognize that pull tape is a critical safety and performance component in electrical and industrial infrastructure. A single failure can lead to costly downtime or damaged conduit. To ensure the highest level of reliability, our manufacturing facility operates under a rigorous multi-stage Quality Control (QC) framework.
1. Raw Material Integrity
We utilize only high-tenacity, low-shrinkage 100% Virgin Polyester yarns. Every shipment of raw material is inspected for fiber consistency and denier accuracy before it enters our weaving looms. This ensures that our tape provides the "low-stretch" performance required for precision cable pulls.
2. Laboratory Testing & Verification
Every production batch undergoes destructive and non-destructive testing in our in-house laboratory to verify:
Breaking Strength (BS) : We perform tensile tests using calibrated Universal Testing Machines (UTM) to confirm that every size meets or exceeds its rated pound-force capacity.
Measurement Accuracy : Our sequential footage and meter markings are calibrated to a tolerance of ±3%, providing a reliable measurement tool for calculating cable runs.
Low Elongation & High Strength | Our tape maintains consistent performance under heavy loads with minimal stretch. This low-stretch property improves pulling efficiency and increases job site safety by reducing the risk of dangerous "snap-back" during unexpected breaks. |
Environmental Durability | Designed to withstand harsh outdoor and underground conditions, our polyester fiber is naturally resistant to UV rays, rot, mildew, and common chemicals. |
User-Friendly Design | The soft, flexible texture is gentle on hands and easy to knot or braid, yet it is resilient enough to resist kinking and twisting during high-speed pulls. |
Sequential Markings | Clear, accurate print markings (available in meters) are integrated into the tape, allowing installers to track progress, measure cable runs precisely, and manage inventory with ease. |
Telecommunications | Ideal for pulling fiber optic and copper cables through underground innerducts. |
Electrical Utilities | Trusted for installing heavy-duty electrical wiring in residential and commercial conduits. |
Cargo & Logistics | Widely used as heavy-duty strapping for securing cargo, gear tie-downs, and industrial bundling. |
Industrial Insulation | Tying and finishing coils in electrical rotating machines (transformers/motors) |
Specialty Uses | Suitable for agriculture, gardening, and even recreational uses like hanging hammocks due to its extreme load capacity. |
Custom Tensile Strengths | Ranges from light-duty 400 lbs to ultra-heavy 6,000 lbs. |
Tailored Lengths | Available on sturdy plastic reels or wooden drums in lengths ranging from 500 ft to all possible required lengths. |
Private Labeling | Custom branding is available for organizational or retail purposes. |
Applications
(1).png)
